XK-230 Two Roller Mixing Mill Machine
Product Overview
Professional two roller mixing mill machine designed for efficient rubber compounding and mixing applications with long service life and reliable performance.
Technical Specifications
Model
XK-230
Roll Diameter
230mm
Roll Working Length
615mm
Capacity Per Batch
6-10kg
Power
15kW
Voltage
208/220/380/415/480V etc.
Automatic Grade
Automatic
Service Life
Longer Than 15 Years
Complete Model Range Specifications
| Item |
XK-160 |
XK-250 |
XK-360 |
XK-400 |
XK-450 |
XK-550 |
XK-560 |
XK-660 |
XK-710 |
| Roll diameter (mm) |
160 |
250 |
360 |
400 |
450 |
550 |
560/510 |
660 |
710 |
| Roll working length (mm) |
320 |
620 |
900 |
1000 |
1200 |
1500 |
1530 |
2130 |
2200 |
| Front roll linear speed (r/min) |
9 |
16.3 |
16.7 |
19.3 |
21.8 |
22.5 |
27.2 |
28 |
31.9 |
| Speed ratio of rolls |
1:1.4 |
1:1.1 |
1:1.3 |
1:1.3 |
1:1.3 |
1:1.2 |
1:1.2 |
1:1.2 |
1:1.5 |
| Max roll space (mm) |
4.5 |
8 |
10 |
10 |
12 |
16 |
15 |
0.5-15 |
0.5-15 |
| Compound feeding capacity (kg) |
1-2 |
10-15 |
20-25 |
18-35 |
50 |
50-65 |
50-65 |
165 |
190 |
| Motor power (kW) |
5.5 |
18.5 |
30 |
45 |
55 |
110 |
90 |
240 |
280 |
| Dimensions L (mm) |
1133 |
2722 |
4200 |
4920 |
5405 |
6646 |
6270 |
7280 |
8185 |
| Dimensions W (mm) |
920 |
1115 |
1780 |
1780 |
1740 |
2736 |
2282 |
3400 |
3910 |
| Dimensions H (mm) |
1394 |
1345 |
1760 |
1800 |
1790 |
2105 |
2000 |
2530 |
2270 |
| Gross weight (T) |
~2 |
~3.2 |
~6.5 |
~8 |
~11.4 |
~22 |
~22.5 |
~49 |
~51 |
Key Features
- Superior mixing performance for consistent compound quality
- Low operating cost with high productivity output
- Compact construction for maximum floor space utilization
- Latest technology meeting current world standards
- Minimal maintenance requirements
- Reliable and experienced service support
- Easy installation and ready-to-run operation
- No continuous lubrication required, reducing operational costs
- Auto reversing electric panel for enhanced control
- Simple and easy maintenance procedures
Quality Assurance Testing
All rubber mixing mills undergo comprehensive factory testing before delivery. Each machine is fully assembled with pre-connected wiring between motor and control cabinet, requiring only external connections upon installation. Every unit undergoes 4-6 hours of load testing to minimize on-site debugging time and costs.
Frequently Asked Questions
Delivery time for rubber machines?
Custom-designed machines require 25-35 days from engineering design to production completion.
Quality control procedures?
Comprehensive quality control throughout production with full assembly and testing before shipment.
Machine quality guarantee?
One-year quality guarantee using world-famous brand components for reliable performance.
Overseas installation and commissioning?
Available with technical support (customer covers installation costs). Small machines: 2-3 days; Large plants: ~30 days.
How to verify machine quality?
We deliver exactly as ordered with innovation, quality, integrity and efficiency as core values. References available from world-renowned rubber manufacturers.
Factory location and access?
Located in Qingdao City, Shandong province, China. Airport pickup available from Qingdao Liuting airport.
Our machinery has been exported to America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonesia, Australia, Sri Lanka and many other countries worldwide.
