400T Rubber Hydraulic Hot Plate Vulcanizing Press
Product Overview
Professional 400-ton hydraulic hot plate vulcanizing press designed for rubber manufacturing applications, featuring advanced PLC control and customizable configurations.
Technical Specifications
| Parameter |
Value |
| Model Number |
1200x1200 |
| Total Pressure |
400 MN |
| Plate Size |
1200 * 1200 mm |
| Gross Weight |
9500 kg |
| Power |
10-100 kW |
| Voltage |
380V |
| Service Life |
≥15 Years |
| Structure |
Vertical |
| Certifications |
CE1282, ISO9001:2008, SGS |
Technical Parameters Comparison
| Parameter Type |
XLB-240*240*2 |
XLB-350*350*2 |
XLB-400*400*2 |
XLB-500*500*2 |
XLB-600*600*2 |
XLB-700*700*2 |
XLB-750*850*2 |
XLB-900*900*2 |
| Total Pressure (MN) |
0.15 |
0.25 |
0.5 |
0.63 |
1.00 |
1.20 |
1.60 |
2.00 |
| Plate Distance (mm) |
125 |
125 |
125 |
125 |
125 |
125 |
200 |
300 |
| Working Layer NO. |
2 |
2 |
2 |
2 |
2-4 |
2 |
2-4 |
2 |
| Unit Pressure (Mpa) |
2.60 |
2.04 |
3.13 |
2.52 |
2.77 |
2.45 |
2.51 |
2.47 |
| Plunger Stroke (mm) |
250 |
250 |
250 |
250 |
250/400 |
250 |
400 |
400 |
| Heating Mode |
Electricity |
Electricity |
Electricity/Stream |
Electricity/Stream |
Electricity/Stream |
Stream |
Electricity/Stream |
Stream |
| Motor Power (KW) |
2.2 |
2.2 |
2.2 |
2.2 |
2.2 |
2.2 |
3 |
5.5 |
| Size: (L* W* H)(mm) |
1200*350*1300 |
1400*480*1380 |
1600*500*1480 |
1750*600*1540 |
1880*720*1680 |
2000*850*1750 |
2250*1200*2200 |
1400*900*2400 |
Key Features & Advantages
- 20 years of expertise in rubber vulcanizing press manufacturing and exporting
- Fast delivery within 30 days
- Safety wood or plywood crates packing with full transportation insurance
- Global reach - sold to 126 countries across 6 continents
- One-stop rubber machinery solutions from Qingdao Shun Cheong
- Specifically designed for manufacturing special seal rings in petroleum mechanical applications
- Advanced PLC control system for precise operation
- Customizable configurations to meet specific customer requirements
- Innovative design concepts backed by strong technical expertise
Quality Assurance
Each rubber vulcanizing press undergoes rigorous 24-hour pressure testing before delivery, including pressure maintenance tests to verify hydro-cylinder bearing capacity and piston stroke performance. This ensures no oil leakage or seepage, preventing potential quality issues.
Custom Manufacturing
We specialize in designing and manufacturing non-standard rubber vulcanizing presses tailored to specific customer requirements and applications.
Packaging & Shipping
Equipment is professionally painted and wrapped with protective stretch film to prevent surface damage. Custom wooden packaging is available, with key components like electronic control boxes receiving additional shockproof packaging before being secured in wooden cases.
Global Export Network
Our rubber vulcanizing presses have been successfully exported to numerous countries including America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonesia, Australia, Sri Lanka, and many others.
